Main Technical Specifications

(1)Max negative pressure value:≥0.075MPa

(2) Adjustable negative pressure range: 0.02MPa ~ Max negative pressure value

(3) Pumping rate: ≥18L/min

(4) Sound Level : ≤60dB（A）

(5) Suction bottle : 1000mL

(6) Power supply :AC220V/110V,50/60Hz

(7) Input power :250VA

(8) Fuse tube : F1.6AL 250V Φ5*20mm

(9) Dimension: 360*235*230mmmm

(10) Period of validity: 5 years.

●The aspirator is not suitable for use in the place with inflammable & explosive gas.

●Operating mode:non-continuous(20 minutes ON/40 minutes OFF)

●Electric safety requirement :Class II
